    Ar Class of Operation AC240V DC150V Bolt Connected Fast Speed Fuses with 5A 50A 100A 160A 200A 300A 400A 500A 600A 700A 800A 900A

    Ask Lasest Price
    Supply Ability : 5000/Month
    Brand Name : Golden Electric /OEM
    Certification : ISO 9001, ISO 9000, ISO 14001, ISO 14000, ISO 20000, OHSAS/ OHSMS 18001, IATF16949
    Delivery Time : Peak Season Lead Time: more than 12 months Off Season Lead Time: within 15 workdays
    Payment Terms : LC, T/T, PayPal, Western Union
    • Product Details
    • Company Profile

    Ar Class of Operation AC240V DC150V Bolt Connected Fast Speed Fuses with 5A 50A 100A 160A 200A 300A 400A 500A 600A 700A 800A 900A


    Product Description


    The BS88 series fuses are fuses with fuse-links having bolted connections. Such fuses have rated currents up to and including 1 250 A and rated voltages up to and including 690 V ac and up to and including 500 V dc.


    Features & Benefits

    BS88 type

    Wide range of protection applications


    Applications

    Cable protection

    Motor circuit protection

    Capacitor circuit protection

    Transformer protection

    Product Parameters

    Product Series

    Bolt type Series

    Voltage

    Up to 690Vac/500Vdc

    Current

    Up to 900A

    Operating class

    IEC60269-2

    Country of Origin

    China


    Product Details

    AC240V DC150V Bolt Connected Fast Speed Fuses with 5A 50A 100A 160A 200A 300A 400A 500A 600A 700A 800A 900AAC240V DC150V Bolt Connected Fast Speed Fuses with 5A 50A 100A 160A 200A 300A 400A 500A 600A 700A 800A 900A

    ModelRated Current(A)Pre-arc(I²t)Total(I²t)
    CFS-1051.311
    CFS-1061.815
    CFS-10102.420
    CFS-10124.333
    CFS-10166.748
    CFS-102015100
    CFS-102527160
    CFS-103253280
    CFS-1771.39.8
    CFS-17104.523.6
    CFS-17125.931
    CFS-171611.259
    CFS-172015.6100
    CFS-172530160
    CFS-173045235
    CFS-173563330
    CFS-1750160940
    CFS-17602501310
    CFS-17753801990
    CFS-17804802530
    CFS-171007304060
    CFS-171258506920
    CFS-1715012509590
    CFS-17160173011700
    CFS-17180209017500
    CFS-3850120500
    CFS-38753301380
    CFS-381007453060
    CFS-3812513405500
    CFS-3815019307950
    CFS-38200402016400
    CFS-38250535030000
    CFS-38300729049600
    CFS-383501800074000
    CFS-3840025100128000
    CFS-3845033500170000
    CFS-3850043000219000
    CFS-3852548200245000
    CFSS-38300770031800
    CFSS-383501150048700
    CFSS-384001600065600
    CFSS-384502100087000
    CFSS-3850029100120000
    CFSS-3863048200198500
    CFSS-3871072000276000
    CFSS-38800100000512000
    CFSS-38900134000680000
    CFSS-381000172000876000
    CFSS-381050193000980000


    AC240V DC150V Bolt Connected Fast Speed Fuses with 5A 50A 100A 160A 200A 300A 400A 500A 600A 700A 800A 900AAC240V DC150V Bolt Connected Fast Speed Fuses with 5A 50A 100A 160A 200A 300A 400A 500A 600A 700A 800A 900AAC240V DC150V Bolt Connected Fast Speed Fuses with 5A 50A 100A 160A 200A 300A 400A 500A 600A 700A 800A 900A

    ModelRated Current(A)Pre-arc(I²t)Total(I²t)
    CFS-10P51.315
    CFS-10P61.321
    CFS-10P103.335
    CFS-10P123.558
    CFS-10P169.7100
    CFS-10P2019.4200
    CFS-17P169.7107
    CFS-17P2017.3185
    CFS-17P2527285
    CFS-17P3253570
    CFS-17P3570725
    CFS-17P40981080
    CFS-17P451301280
    CFS-17P501561420
    CFS-17P552101970
    CFS-17P633152850
    CFS-17P755254630
    CFS-17P806255700
    CFSS-17P652102270
    CFSS-17P753103280
    CFSS-17P854304350
    CFSS-17P905255130
    CFSS-17P1108507840
    CFSS-17P140173015700
    CFSS-17P150209018500
    CFSS-17P160250022800
    CFS-38P50180990
    CFS-38P653351840
    CFS-38P753502000
    CFS-38P854804000
    CFS-38P907204700
    CFS-38P11011806900
    CFS-38P150288014500
    CFS-38P180535025500
    CFS-38P200951046000
    CFS-38P25021400110000
    CFS-38P28029100145000
    CFS-38P31536100180000
    CFS-38P35548200215000
    CFS-38P40072000305000
    CFSS-38P175288016000
    CFSS-38P200335018400
    CFSS-38P235390020000
    CFSS-38P3001370068000
    CFSS-38P32521400102000
    CFSS-38P35525200120000
    CFSS-38P40065600340000
    CFSS-38P45075300390000
    CFSS-38P50085600440000
    CFSS-38P630152000720000
    CFSS-38P710193000800000
    CFSS-38P8002820001220000
